Skellefteå Hosts Euro Mine Expo 2014
The Swedish conference and exhibition promises to be the best ever
By Steve Fiscor, Editor-in-Chief
Euro Mine Expo 2014 will be the fourth rendition of this event. Taking place every two years on the even years, the conference and exhibition has grown consistently since its inception in 2008. A total of more than 2,000 people attended Euro Mine Expo 2012, according to Jaana Tengman, project manager for Nolia, the group organizing the event in conjunction with Georange. “That attendance figure was double the previous figure [2010] and we have managed to sustain the momentum as this year’s attendance is still growing significantly,” Tengman said. “We are well past the registration levels of two years ago and it’s still very early in the process.”
At the end of March, the number of companies reserving stands for the exposition side of the event stood at more than 200. All of the indoor space had been booked by the end of 2013. “We added more indoor space last year, growing from two to three exhibition halls,” Tengman said. “The only remaining space is now in the outdoor area.”
Swedish iron ore miner LKAB is the largest exhibiting company. Of the nine companies sponsoring the event (Atlas Copco, Bergteamet, Björkdal, Boliden, Northland Resources, Outotec, Raw Materials Group, SRK Consulting and Nasdaq OMX), three are mining companies. Other mining companies, such as Agnico Eagle, LKAB and Zinkgruvan, are also exhibiting at the event. In addition to talking to potential customers, suppliers and subcontractors, many of the mining companies are actively recruiting, Tengman explained. “The mines in Sweden are thriving and the companies are searching for talent,” Tengman said. “We have also been working with the technical universities to introduce more students to future employers.” While Euro Mine Expo certainly has a Nordic theme, the event is attracting interest from other European countries and beyond, as can be seen from the technical program outline and the list of exhibiting companies.
The three-day event kicks off in the afternoon on Tuesday, June 10 with opening remarks from one of the organizers, Lennart Gustafsson, chairman, Georange. Magdalena Andersson, governor, County Administrative Board of Västerbotten, will preside over the opening. Jonas Hafström from Sweden’s Ministry for Foreign Affairs will discuss the significance of the mining business. In his keynote address, Lars-Eric Aaro, CEO, LKAB, will set the tone for the event.
A technical program runs through the course of the event. The first session focuses on mining and Europe. The second session will discuss investments in the mining industry and the program will conclude on Thursday, June 12, with presentations covering recent technological advances taking place in the industry. “The program committee has put a lot of effort into finding great speakers that everyone will find interesting,” Tengman said. A number of other satellite workshops and discussions are orbiting the main technical program along with three field trips to mining-related points of interest in the region.
The organizers have also created a networking opportunity for the delegates. “In 2012, we had Match Making hosted by Enterprise Europe Network for a fee and now that is included in the registration for all delegates,” Tengman said. “Delegates can book meetings with each other through an interactive calendar. Almost half of the current registrants have elected to participate in this program. The ability to pre-book meetings is very popular.” Several hospitality events also have been organized for the early evening hours. Participation in these ticketed events is limited. Tengman promises that the food will be spectacular.
The exhibition runs from 9 a.m. to 6 p.m. Tuesday and Wednesday and from 9 a.m. to 3 p.m. on Thursday. E&MJ spoke with a number of exhibitors, asking them what they planned to showcase for this market. Many preferred to keep it a surprise, but the ones who shared follow:
Elevators from Alimak Hek
Alimak will display its rack and pinion elevator. The elevators
are a perfect solution for underground as well as aboveground
applications, such as pelletizing plants, smelters, concentrators, crushers and other ore processing plants.
Since the introduction of the Raise Climber in 1957, the “Alimak Method” has been used to drive more shafts and raises than any other raise climber system, increasing mining productivity and raising industry safety standards. With Raise Climber now sold exclusively through Arkbro Industries, Alimak Hek’s focus today is on industrial elevator solutions.
Following the first underground elevator installation in the early 1960s, mining is now at the heart of Alimak Hek’s business, with thousands of above and below ground mining elevators delivered worldwide. Recent installations include:
• Seven elevators for Northland Resources, Kaunisvaara, Sweden;
• Five elevators for Boliden, Garpenberg 2.5, Sweden;
• One elevator for Boliden Rönnskär, Sweden; and
• Three elevators for Crushing Services International, Christmas Creek mine, Australia.
Atlas Copco’s Rolls Out the Heavy Gear
Atlas Copco recently launched a new, 18-metric-ton (mt)
capacity underground loader for large operations including development work as well as production mining. The company
expects the Scooptram ST18 to be the most productive LHD on
the market and it will showcase the LHD at Euro Mine Expo.
“We know that this loader is long-awaited on the market,” said Ben Thompson, product manager for Atlas Copco. “The optimized bucket means better muck pile penetration, faster acceleration and faster dumping. The result is a better load factor on the truck and, in the end, a higher tonnage per month.”
The machine was designed to match the 60-mt capacity Minetruck MT6020. The two pieces of equipment share many common parts and control system components, which can substantially reduce total cost of ownership. The bucket and the boom design combined with variable displacement pumps provide safe and efficient operations. This, together with the Rig Control System, which monitors, supports, and controls all aspects of the operation, results in superior muck pile penetration, less wear and tear on the machine, and an overall faster and more productive loading cycle, according to Atlas Copco.
CraneX Offers Lifting Solutions
CraneX AB offers services such as maintenance and modernization
of hoists, cranes, telfers and industrial gearboxes.The company
offers solutions with high focus on customer need, reliability and
safety. The areas of expertise include service, modernization, and
new deliveries of lifting equipment and rotating machines.
Dynaset Blue Hydraulics
Dynaset is a leading manufacturer of hydraulic generators,
power washers and compressors. The company has created a
whole new industry of equipment powered by hydraulics that
transforms hydraulic power of a machine into electricity, highpressure water, compressed air, magnet, vibration, etc. for hundreds of different applications. Dynaset equipment increases
productivity of customer’s mobile machinery by diversifying its
features. Zero emission Dynaset equipment runs without extra
engines or additional fuel. Dynaset equipment is integrated in
a machine and they are always ready to use.
IDS Defines New Standards for Slope Monitoring
The Italian radar manufacturer, Ingegneria dei Sistemi IDS,
with more than 100 installations of its radar systems in openpit mines all around the world, is defining a new standard in the
safety critical slope monitoring for the mining sector. The long
record of successfully tracked failures has been possible by the
innovative radar technology employed by the IDS IBIS radar.
The IBIS system is based on a Synthetic Aperture Radar (SAR)
technology, which is able to provide the highest spatial resolution at the longest range distance available on the market, along with the fastest acquisition time. These features fulfill the
needs of both safety critical slope monitoring and background
monitoring of the largest mines currently in operation.
PANalytical Solution for Process Industries
For more than a decade, PANalytical has provided a wide range of
analytical solutions for process industries. Since 2010, this has
included the Controlled Neutron Analyzer (CNA), which features
PFTNA (Pulsed Fast and Thermal Neutron Analysis), a state-of-theart neutron tube technology. The CNA was first used in the cement
industry to measure and control the quality of their raw materials.
More recently, the applications for PFTNA have grown to include
other materials and industries—hard and soft rock mining.
To meet the demands of these varied applications, PANalytical has introduced the CNA3 for a number of different applications. The core of the CNA is unchanged. The unit employs Sodern Neutron Technology that includes their longlife neutron tube (more than 12,000 working hours) and durable BGO (Bismuth Germanium Oxide) gamma ray detectors. The CNA 3 features a new configuration specifically designed for the high-belt loading found in these industries. Since both the neutron tube and the detectors are located underneath the belt, the CNA3can fit virtually any size belt and accommodate a wide range of belt loadings. The small unit (1,200-mm wide x 1,400-mm long x 615-mm high) is installed on a rail system that slips under the belt. This significantly reduces installation effort and allows simple removal for calibration and maintenance without interrupting production.
A CNA3 Iron was recently commissioned at an LKAB mine. The unit was first installed in a test configuration on the surface. After passing all of the preliminary tests, the unit was approved for underground installation and is currently operating 815 m underground and providing real-time analyses of the material exiting the mine.
Heavy-duty Roller for High-speed Conveying
Longer life with increased capacity and lower energy consumption (lower CO
2
emissions), quiet and easy handling; these are
the benefits Sandvik targeted when designing its new generation
of formed conveyor rollers. The HM150 is now performing successfully in the new overland conveyor at the Aitik copper mine.
Higher belt speeds and heavier loads pose additional challenges to rollers as far as bearing life, noise and power demands. A conveyor roller fails prematurely because of bearing overload or contamination, excessive shaft deflection, vibration or shell wear and/or corrosion. Sandvik rollers are designed to provide a quality product addressing all of these issues.
The HM150 is a formed roller to operate in applications characterized by conveyor capacities ranging from 3,000 to 50,000 tons per hour, belt speeds from 4 m/s to 12 m/s and belt widths from 1,400 to 3,000 mm.
Based on innovative and new design and optimized components and manufacturing processes, the formed rollers operate longer, quieter and consume less energy than traditional high speed rollers. The increased roller life, reliability, and energy efficiency create new opportunities to reduce downtime and maximize belt speed.
SRK Consulting Contributes Expertise
SRK Consulting (Sweden) AB was established in 2009 in
Skellefteå, Sweden, to support mining operations and development projects in the Nordic region. The company has been
associated with Euro Mine Expo since 2010. At this year’s conference, SRK will present two talks and hold a technical workshop. Dr. Päivi Picken, senior consultant (environment), will
present: Environmental Permitting Experiences in Finland and
Sweden—Differences, Challenges, Primary European Union
Legislation, as part of the main conference program.
In addition, SRK will be presenting on “Implicit Modeling” and also the application of an “Integrated Approach in Hydrogeology” at the Exhibitors Innovation Forum.
A technical workshop will be run in parallel with the Expo. The title of SRK’s workshop is, Application of SRK’s recent mining and geotechnical experience in the Nordic Region. SRK will cover recent experience of practical mining and geotechnical considerations in mine planning through to operations. The main topics will include:
• Pit slope failure remediation and impact on the mine plan;
• Proactive pit slope optimization;
• Considerations during optimal bench height selection;
• Practical aspects of strategic mine planning;
• Early and late stage geotechnical data capture;
• Geotechnical considerations during open-pit operation startup;
• Mining method transition;
• Practical applications of numerical modeling; and
• Ground monitoring.
The workshop will be held by Dr. Xander Gwynn, senior consultant (Geotechnical Engineering), Maxim Lesonen, consultant (Mining Engineering), and Michael Di Giovinazzo, senior consultant (Geotechnical Engineering).
Teufelberger Supplies Steel Wire Rope
With more than 220 years of experience, Teufelberger manufactures steel wire ropes for ropeways, cranes and shaft hoists. For
shaft hoists guide ropes, the company offers both locked coil
and half locked coil ropes. More recently, the company has introduced the Solitec hoisting rope and TEKA Mining hoisting ropes.
